The McIntosh MC3500 Vacuum Tube Amplifier Mk II is a high-power monoblock amplifier meticulously re-engineered from the legendary amplifier that powered Woodstock. Delivering a robust 350 Watts into 2, 4, or 8 Ohms, it effortlessly drives any loudspeaker, providing a captivating tube sound with incredible headroom.

It employs McIntosh’s patented Unity Coupled Circuit™ and a tube complement of eight EL509S output tubes, plus three 12AX7A and one 12AT7 for the driver stage. Advanced protection includes Power Guard Screen Grid Sensor™ and Sentry Monitor™. Its stunning retro-modern design features a polished stainless steel chassis, gold-anodized machined aluminum front panel with a DualView™ output meter, ergonomic handles, and a protective tube cage. With balanced and unbalanced inputs, the 121-pound MC3500 Mk II offers a truly immersive, reference-level audio experience.

- The MC3500 Vacuum Tube Amplifier Mk II is a conservatively rated 350 Watt monoblock that takes its inspiration from the original 1968-71
MC3500, and incorporates everything we have learned about vacuum tubeamplifier design since the 1960s.

- Upgraded to modern standards and with modern components to deliver an audio performance worthy of its predecessor and the legacy of their
shared model number.

- Uses our Unity Coupled Circuit output transformer, which allows the full 350 Watts to be safely delivered to virtually any speaker regardless if it has 2, 4 or 8-Ohm impedance.

- Output powered by eight EL509S high-power output vacuum tubes, which was chosen specifically due to it having many similar qualities and
characteristics of the 6LQ6 “sweep tubes” used on the original MC3500.

- Like the original MC3500, the MC3500 Mk II has a fully balanced driver section that utilizes three 12AX7A and one 12AT7 vacuum tubes.

- Power Guard Screen Grid Sensor™ (SGS) helps prevent premature vacuumtube failure by monitoring the screen grid current in the output tubes. If the current becomes too high, Power Guard SGS dynamically attenuates the input signal in real time to keep the vacuum tubes operating at safe levels.

- Sentry Monitor™ observes the output current and shuts the amplifier off ifit ever exceeds safe limits.

- Uses a variation of our DualView™ Power Output Meter design, with thetop scale showing the power output in both Watts and decibels, while the bottom scale shows the amplifier warmup time.

- Front panel is machined aluminum with a bead blast finish and gold anodizing that emulates the look and finish of the original MC3500. A clear glass insert covers the meter; a black glass insert at the bottom houses the knobs and illuminated lettering.

ELECTRONIC SPECIFICATIONS

Power Output per Channel:350W @ 2, 4 or 8 Ohms
Number of Channels: 1
Total Harmonic Distortion:
- 0.3% maximum harmonic distortion at any power level from 250 milliwatts to rated power, 20Hz to 20,000Hz
S/N below rated output:120dB
Dynamic Headroom:2.4dB
Damping Factor:>25 Wideband
Rated Power Band:20Hz to 20kHz
Frequency Response:
- +0, -0.5dB from 20Hz to 20,000Hz
- +0, -3.0dB from 10Hz to 70,000Hz

CONTROL

Remote Power Control:Yes
Multi-Channel DB25 Cable:N/A

GENERAL SPECIFICATIONS

Circuit Configuration:Unity Coupled
Circuit Design:Vacuum Tube
Mono Bridge:No
Mono Parallel:No
Output Type:Unity Coupled Output Transformer
Meters:Yes
Meter Light Switch:Yes
Balanced Input:Yes
Front Panel:Machined aluminum with handles
Illumination:Direct LED
Chassis Style:Polished stainless steel

CONNECTIVITY

Speaker Binding Post Type:Patented Solid Cinch™ Speaker Binding Posts

WEIGHTS & DIMENSIONS
Unit Dimensions (W x H x D):
- 18" (45.7cm) x 11-13/16" (30cm) x 21-5/8" (54.9cm)
Unit Weight:121 lbs (54.9 kg)
Shipping Weight:147 lbs (66.7 kg)
