Overview
The MEN220 delivers a potent suite of Room Correction, Custom-EQ and 2-Way Crossover capabilities in one easy-to-use stereo component. While any single feature of the MEN220 has the power to optimize the sonic characteristics of the highest quality audio systems, combining all the features can reveal a level of clarity and resolution unattainable by any other means.
“I have never heard my speakers sound so wonderful!” – Michael (McIntosh customer review)
The new MEN220 Room Correction System by McIntosh delivers a potent suite of Room Correction, Custom-EQ and 2-Way Crossover capabilities in one easy-to-use stereo component. While any single feature of the MEN220 has the power to optimize the sonic characteristics of the highest quality audio systems, combining the features can reveal a level of clarity and resolution unattainable by any other means. Styled in the rich tradition of McIntosh audio components the MEN220 features our trademark Fiber-Optic Illuminated Black Glass Front panel and aluminum casework. Front panel buttons and control knobs bring a familiar, easy-to-use analog interface to this digital product just as a 2-line vacuum fluorescent display reports status and aids in the set-up of the MEN220. Full system control and PC link are provided via RS232 while McIntosh Data, Power Control andIR inputs offer additional remote control flexibility. Both single-ended and balanced connections are supported; a hand-held, IR remote control is included.
- Create custom curves w/PC Interface
- 2-way Electronic Crossover for Bi-amp
- Integrate Mono or Stereo Subwoofer
- Preserves tonality of a loudspeaker while eliminating room-interaction
- Greatly enhances the quality of imaging width and depth
- IR Remote Control
- RS-232
Unless otherwise noted, the below MEN220 Specifications were taken with RoomPerfectTM set to Bypass Mode and Voicing Mode set to Neutral.
Frequency Response: +0, -0.5dB from 20Hz to 20,000Hz
Total Harmonic Distortion:0.002% from 20Hz to 20,000Hz
Maximum Input Signal:
- 4.5V Unbalanced and Balanced (Low Sensitivity)
- 2.25V Unbalanced and Balanced (High Sensitivity)
Maximum Volatge Output:
- 4.5V Unbalanced and Balanced (Low Sensitivity)
- 2.25V Unbalanced and Balanced(High Sensitivity)
Signal to Noise Ratio:(A-WEIGHTED) 100dB
Input Impedance:10K ohms Unbalanced and Balanced
Maximum Input Signal:4.5 Unbalanced and Balanced
Voltage Gain:0dB
Output Impedance:50 ohms
GENERAL SPECIFICATIONS
Power Requirements:
- 100V ~ 50/60Hz at 35 watts
- 110V ~ 50/60Hz at 35 watts
- 120V ~ 50/60Hz at 35 watts
- 220V ~ 50/60Hz at 35 watts
- 230V ~ 50/60Hz at 35 watts
- 240V ~ 50/60Hz at 35 watts
- Standby, less than 1 watt
- Note: Refer to the rear panel of the MEN220 for the correct voltage.
OVERALL DIMENSIONS:
Width: 17-1/2 inches (44.45cm)
Height: 6 inches (15.24cm)including feet
Depth: 18 inches (45.72cm)including the Front Panel, Knobs and Cables.
Weight:25.5 pounds (11.6 kg) net, 41.9 pounds (19.0 kg) in shipping carton.
